2D wired Barcode Scanner WD-S5
2D wired Barcode Scanner WD-S5
Features:
1.Multiple languages
2.Full ASCII character editing
PARAMETER:
| Type: | 2D wired Barcode Scanner |
| Interface: | USB，USB-COM |
| Working current： | 3.3-5Vx200mA (idle≤70mA) |
| Storage： | 3670 barcodes (EAN13) |
| Sensor： | 640x480 CMOS |
| Resolution： | 1D≥4mil,2D≥10mil |
| Indication： | Buzzer & LED |
| Trigger ： | Button，Continuous，Auto-sense |
| Scanning angle： | rotation360°，inclination± 55°，declination ± 55° |
| Decode Capability： | 1D：UPC, EAN, ISBN, ISSN, Code 128, Code 39, Code32, Code 93, Interleaved 2 of 5, industrial 2 of 5, Matrix 2 of 5, IATA 2 of 5, MSI Plessey, Code 11，Codabar, GS1 Data Bar. 2D:QR, Micro QR，Data Matrix，PDF417，MicroPDF417，Aztec, Maxi Code |
| LED life： | 100000 hours |
| Button life ： | 1000,000 times |
| Drop test ： | 1.5m |
| REGULATORY: | CE, FCC, RoHS |
ENVIRONMENT:
| Operating Temp. ： | -20℃ to 50℃ |
| Storage Temp. ： | -40°C to 70°C |
| Humidity： | 5% – 95% non-condensing |
