WD-80R12 80mm thermal receipt printer
WD-80R12 80mm thermal receipt printer
Paper out alarm, Overheat protection
| Type | 80mm thermal receipt printer |
| Printing method | Direct Thermal |
| Interface | USB standard |
| Dot density | 8dots/mm, 576dots/line |
| Printing speed | 160-200mm/s (25% printing density) |
| Print paper width | 79.5mm ± 0.5mm |
| Western Language | 12×24 points |
| Chinese language | 24×24 points |
| Power requirements | DC24V, 1.25A, 3P power socket |
| Paper type | Ordinary thermal paper 79.5mm × medium 80mm (MAX) |
| Paper thickness | 0.06~0.08mm |
| Maximum outer diameter | Medium 80mm |
| Minimum inner diameter | Medium 13mm |
| Dimension | 167mm × 129mm × 120mm (L × W × H) |
| Print head lifespan | 100km |
| Knife lifespan | 1,000,000 times |
| Options | USB+LAN:+1.86$ USB+BT:+2.57$ USB+WIFI:+2.57$ |
| Packing List |
1unit： 23*22*16.5cm 1.5KG 18pcs/ctn: 68*48*52cm 29KGS |
